Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration System

Name: Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration System
Brand: YICHENG
Price: 1 USD

Buy cheap Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration System product

Place of Origin : China

Brand Name : YICHENG

Certification : CE

Model Number : CG series

MOQ : one piece

Price : negotiation

Packaging Details : Carton

Delivery Time : 7-10 days

Payment Terms : Ex-worked

Supply Ability : 100PCS/week

Contact Now

Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration

Description:

Product features:
* using food grade high density polyethylene (HDPE) material, corrosion resistance, safer, more environmentally friendly
* the body adopts the integration of thermoforming, makes the body is stronger, more stable quality, can ensure that is not affected by the influence of the bad weather, can make the filter and stable operation for many years
* 6 multi-way valve, combines many functions in one, the only need to handle gently rotating can easily implement, operation more simple
* mixed color machine and line clip round base, allowed to rotate 360 degrees, ease of installation
* size optimization design, save the space machine installation and operation
This product is suitable for: small pool, home swimming pool, SPA pool, aquarium, waterscape fountain, etc

FEATURES:

Easy to Clean

Suitable for use with Automatic Pool Cleaners

High quality 6 position multi-port valve

Self-sealing barrel unions

Transparent lid for inspection of filtered water

Ring lock design for quick opening and closing, Thereby eliminating

The use of traditional screws

* Use only #20 white silica sand, size range 0.4-0.55mm.

Maximum working pressure: 2.5kg/cm² ; Maximum temperature: 50° C(122° F)

Model	Pipe size	Filter Area	Design flow	Sand weight	Tank volume	Tank weight	Valve volume	Valve weight
Model	(inches)	m2	m3/h	0.5-0.8mm (kg)	m3	kg	m3	kg
CG450	1.5	0.16	8.0	50	0.15	7.0	0.02	3
CG500	1.5	0.23	11.5	80	0.20	10.2	0.02	3
CG650	1.5	0.32	16.0	160	0.32	13.1	0.02	3
CG700	1.5	0.40	20.0	220	0.42	18.0	0.02	3

Working pressure: 2.5kg/cm2

Testing pressure: 4kg/cm3

Maximum temperature: 43 degree

Size of sand: 0.5-0.8mm

Side Mount Plastic Swimming Pool Sand Filters For Pools And Ponds Filtration System
